This new type of waterproof microswitch is ideal for a small outdoor applications. its small dimensions (5.3x7.85x8.30mm) body size and robust new design, makes this new series suitable for using in a harsh environment. The switch offers a travel of 3.70mm (with a metal lever) and actuator height of only 3.85mm.

This is an ideal tact switch, offer a very small size ( 3.2x4.2mm), robust design and strong actuation force (400gf). Despite of its small size, the tactile feedback is clear and sharp. You can even use it for “gloved hands” applications. The switch is for SMT assembly, through a standard reflow process.

Tact switches, illuminated by RGB led's, make your system’s panel looks modern. It enable you to choose the color for each button by using only a single product. ADR offers RGB tact switches with a various transparent caps, in different sizes. Switches can be ordered without the caps Different series offer different heights ( PCB to Panel). Range includes both SMT & Through-hole types.

Detector/Tamper switches are commonly used to identify the opening of a cover. It also can be used as a reset button. Almost all of the detectors in the market are Normally-Open. ADR offers a very small, Normally-Close switch. It enable your circuit to remain close until cover is removed. This product is suitable for small packages (usually products operated by batteries).

Dip switches have a big advantage by showing visually the desired code. Number of actuators is up to 12. Terminal options are horizontal/vertical & TH/SMT. Actuators can be raised (easy to use) or flat (hard to use). Flat version enable top-tape seal that helps in p&p assembly.

Slide switches give mechanical advantages to the designer. they have a short rear body and actuator length can be modify easily. for the electronic designer, slide switches offer a big range of functions, includes multi-poles & momentary options.

Tilt switches are mainly used to protect systems against an angular motion. sometimes, it is used to count vibrations or, to act against G force. Each product have its own specific angle to close the circuit/contact. Ball-contact tilt can be vertical or horizontal mounted, with through-hole or SMT terminals.

Coded switches are popular in control systems. ADR offers those switches in 4, 6, 8, 10 & 16 positions configuration. You can get a waterproof (IP67) or low profile options.

Reliable & small. That’s the main advantages of the above micro-switch series. Together with operating travel of 1mm and only 2.7mm width, it gives a perfect indication solution for compact packaging or micro motion systems.

SMT Micro-switch is an ideal solution for mass production HMI interfaces. It gives a soft but very clear feedback for the user. Unlike tact switches, its over-travel enable users to “click” fast and smoothly.

Tact switches are the most popular switches today. They can reach small dimensions as the above example (1.90x2.80x0.50) and still have appropriate tactile feedback.
