Open-frame displays for military outdoor applications, have unique specifications. The cover glass should be chemically strengthened & Anti-reflective coated. Usually it’s a Gorilla or Dragon glass. EMI conductive layer should attached to the back side of the glass (This layer could be used also as a heater). Resistive or capacitive touch is optically bonded on the front side of the glass.

Only 7.2x7.2mm body size & 2.9mm height, this new rotary encoder series for PCB, enable space saving. It also suitable for harsh environment by providing wide temperature range (-40/+85 ℃), and waterproof sealing (IP67). Those features makes it a perfect solution to outdoor hand-held applications. 3 Types of code are available: Real, Complementary & Gray. Number of positions can be 4, 10 or 16.

This rotary encoder series, have both shaft & housing made of steal. Its small size and flat design makes it very useful for small hand-held devices. It offers a waterproof version for outdoor applications, by fixing the shaft to the panel with O-Ring. The temperature range is wide –30/+85 ℃. Life cycle is quite high—more than 100,000. Detent force between positions can reach 2.5 Ncm, to get a clear tactile feedback. You may also get it without any detent between position

This new robust optical encoder designed for harsh environment. Rotation & push force are strong. It gives a clear feedback even with gloves. Both shaft & panel are protected with O-Rings. Temperature range is –40/+85 ℃ (storage) and humidity can reach 99%. Electrical function is 20 positions + momentary Push. Supplied voltage is 5V. The optical contacts ensure high reliability of the product during operation—more than 500,000 cycles.

ADR supply reliable and durable Valve connectors in 3 combinations: Attachable, Molded and M-connector at the opposite side. Each product have its own relevant base. The connectors conforms EN175301-803(DIN43650). The range includes 2P & 3P + PE. Some of the products are UL or ATEX approved. ADR offers 3 main forms: A, B & C. All products are IP-67 protected and made of UL94-V0/V2 materials.

Valve connectors can include electronics protection and light indication. ADR product’s line of valve connectors, include standard combinations as follow: *Bipolar Led * Bipolar Led + Varistor * Led + Diode(1A) *Full-Wave Bridge Rectifier + Varistor *Full-Wave Bridge Rectifier (3A)+ Varistor (3A) +Led.

M-Connectors for cables are divided into 2 major groups: Field attachable & over molding. While the first option is usually an “off the shelf” product, the second is mostly a custom product. The advantages of over-molding are better protection & time saving for the user. The cable type matched the application demands or, can be dictated by the end user. The connector itself is made for harsh environment (IP-66/68) and made of Brass or Nylon+GF

M-connectors for panel-mount can be made of Brass or Nylon+GF. They are all waterproof ( IP-66/68 ) and suitable for harsh environment. Standard Temp. range is –40/+85 ℃ but, some versions can reach up to 160 ℃. Assembly is wires or directly to a PCB. Bushing style can be a thread or bayonet. ADR range include diameters between 5 to 23mm and up to 17 contacts. The M-Connectors are mostly used for signals transfer but, they also can serve as power transfer ( up to 12A in our r

ADR supply SWIR technologies (wavelengths range from 1,050-2,500 nm), gradually mature, and prices begin to reach feasible levels. A new applications, based on PPG technology adopt it. With improving algorithm, wearable devices are increasingly likely to feature PPG-based bio-sensing functions, which can measure not only heart rate and blood oxygen levels, but also other variables including body hydration as well as blood glucose, blood lipid, and blood alcohol levels in the

ADR supply IR SMD LED’s for laser applications. The main advantages of those LED’s are: High power . Open package. High wavelength stability at different temperatures. Example of parameters: Threshold Current Ith up to 65mA (under 5mW) .

ADR supply UVC LED’s (200-280nm). This range of super short wavelength is very effective for fields as: Counterfeit Detector Phototherapy Disinfection & Sterilization Air purification and more.

IR LED’s Improve Health and Environment Detection for Wearable devices. Via photoplethysmography (PPG), red light and infrared LED’s can receive date from the environment and measure biometric data including heart rate, blood oxygen, blood pressure and blood sugar level. Adopting the sensing components to wearable devices enables a wider range of applications.

This new emergency switch combined 3 elements in one product Switch + Buzzer + Warning Light. Switch function is 2xNC, for 250VAC or 30VDC. Buzzer sound level is 80dB. Warning light is flashing red. The component itself is waterproof (IP65) and suitable for operating temperature range of -25°C/+60°C.

ADR offers a wide range of footswitches for the medical the industrial fields. This range includes some special options: * Water protection up to IP-68 level. * IEC-60601 Medical grade certification. * SPDT, DPDT, Two-Stage, Momentary or Maintained operation.

This new type of waterproof microswitch is ideal for a small outdoor applications. its small dimensions (5.3x7.85x8.30mm) body size and robust new design, makes this new series suitable for using in a harsh environment. The switch offers a travel of 3.70mm (with a metal lever) and actuator height of only 3.85mm.
